  • Building a new drum

    I currently have a Balazs iBox with the 1-1/4" thick manufactured wood drum and it works well, particularly with 50lbs of sand on top of the drum to reduce the vibration. But it’s winter and I was feeling up for a fun little project.

    How thick a platform needs to be is certainly debatable but I’ve always liked the look of the really thick, heavy wood platforms:





    There are two other great examples and build details in this thread: http://www.speedbagforum.com/forums/...ead.php?t=4606

    Originally I was just going to buy a ¼ sheet of ¾” plywood, cut two circles out and glue and screw them to my existing drum but when I checked the price of a ¼ sheet of regular plywood and saw full sheets of 5/8” Baltic birch for not a lot more money I bought a full sheet of the birch. To make transport easier I had the store cut the sheet into eight 2’ x 2’ squares. I never use anything larger than a small size bag so that's plenty big enough for my needs.

    Last weekend a buddy and I made up a jig for his router and cut all the squares into circles and routed a rounded edge for the top and bottom boards. I’ll use 6 or maybe even 7 layers for my Balazs setup in the garage and save a piece or two to add to an old homemade platform I’m going to mount in my basement eventually.

    Stay tuned; pictures to follow.....

  • #2
    Sounds like an awesome project. Do you know the weight of the original iBox drum?
    @ArcSwivel
    #ArcSwivel sigpic

    Comment


    • #3
      Originally posted by rdshackleford View Post
      Sounds like an awesome project. Do you know the weight of the original iBox drum?
      No but I'll try to remember to do a weight comparison when I get ready to mount the new drum.

      Comment


      • #4
        Nice, can't wait to see it

        Comment


        • #5
          Here's the jig we made out of some 16 gauge sheet metal:



          Lots of wooden circles....



          Stacked up:



          Glued and screwed. The top of the drum has the screws showing, there are no visible screws on the bag side.



          I used 7 of the circles which made the drum just under 5" thick. I've probably done 75% of the sanding now but don't have an updated pic (yet).





          That's probably as far as I'm getting this week.

          Comment


          • #6
            Very nice! Do the screws go all the way down into the bag side board? And what kind of glue did you use?

            -Rusty
            @ArcSwivel
            #ArcSwivel sigpic

            Comment


            • #7
              Thanks. Each board was screwed to the one below it one at a time.

              I used some regular wood glue (Lepage's I think) and some PL400 construction adhesive. I was planning on just using the wood glue but found out I didn't have as much on hand as I thought and it was snowing here so I didn't feel like venturing out to the store.

              Comment


              • #8
                NIce work, that'll give you a good solid rebound, that's for sure

                Comment


                • #9
                  I just love the looks of the thick Drums, Yours looks Cool

                  Comment


                  • #10
                    WOW... that is going to be beautiful...overkill, but beautiful!
                    sigpic

                    Comment


                    • #11
                      Thanks Zaza. Yes it's overkill, that's what I do

                      I just saw "Art of the Bag" for the first of many times on the weekend. Well done sir! I thoroughly enjoyed it and so did my wife.

                      Comment


                      • #12
                        Finished sanding, drilling and staining:





                        And the clear.....



                        The old drum weighs about 11 lbs, the new one is about 45 lbs.
                        Last edited by StevieMac; 12-19-2016, 12:31 PM.

                        Comment


                        • #13
                          That is pretty. I like how the recessed mounting holes are inside the bounce area.

                          Now all you need is a crane mechanism to help you adjust the height. 45lbs, wow!

                          Nice job! Keep the installation pics coming.

                          -Rusty
                          @ArcSwivel
                          #ArcSwivel sigpic

                          Comment


                          • #14
                            That is AWESOME!!!!! I love it!
                            sigpic

                            Comment


                            • #15
                              Thanks guys. I'll have it mounted this weekend and will get more pictures of course. Video to follow, eventually...
